Mozart Phono Professional 　Equalizer ampflier

High quality tube Phono EqualizerAmplifier hand made in Japan

For more than 30 years of research and developing of Phono Equalizer amplifier circuitry,
we have been blushed it up the quality of LP reproducing in highest quality.

This is a latest version of this series, which has newly designed power supply circuit both filament and B+ supply.
It enchances quietness and stabiliry and sound quality improvement.

Base on various requirements of the Equalizer requirements other than RIAA curbs, we developed now Mozart Phono Professional here.
It is aiming precision LP records reproduction of MM (moving Magnet) Pick Up Cartridges. with RIAA as well as other various EQ Curbs.
Before 1956, most of records (LP Mon) are manufactured different equalizer curbs other than RIAA

It is coming with a chart of setting of turnover and roll off that enable to optimal equalization curves as a picture.

Features:

＊ Phono equalizer control, turnover and roll-off can play complying with correct equalizer curb each required in 33, 45 and 78 rpm records.

Needless to say that RIAA position gives best performance of Stereo LP records.

Additional technical features:

＊ Using high mu and high gain tube Ecc85/6AQ8, low noise and driving with low impedance character makes high quality passive equalizer circuit.

＊ All components are carefully selected such as high quality aluminum film capacitors and copper film capacitors are used in equalizer circuit.

＊ This is operating with AC100-120 either of 50Hz or 60Hz only. In case of 220-230V AC country, please use Step Down(230V->115V) Transformer.

主な仕様 　Specifications

入力感度 Input sensitivity： ２.５ｍＶ／１ｋＨ／４７ｋΩ（ＭＭ）

許容入力 Maximum Input： ５００ｍＶ

入力インピーダンスInput Impedance：　 ５７ｋΩ

ＲＩＡＡ偏差 RIAA Accuracy： ±１ｄＢ（including All EQ Curbs）

利得 Gain： ３５ｄＢ／１ｋＨ

Ｓ／Ｎ比 S/N Ratio： ７６ｄＢ以上

使用真空管 Tubes：　 ＥＣＣ８５／６ＡＱ８　　３ pcs (本）

出力インピ?ダンス Output Impedance ： ４．５ｋΩ（１ｋHz）
　　
推奨インピーダンスは１０KΩ以上　

消費電力 Power Consumption： ３０Ｗ

電源電圧　AC Voltage: 100 to 120VAC (50/60Hz)

寸法 Dement ions： 330（Ｗ）ｘ280（Ｄ）ｘ115（Ｈ）ｍｍ

重量 Weight： 5.5ｋｇ

I ship it via EMS post tractable or other courier Services like UPS, FedEx or DHL etc., insured worldwide.

If you have any questions, please feel free to contact me.

Thank you for looking.Features:

＊ Phono equalizer control, turnover and roll-off can play complying with correct equalizer curb each required in 33, 45 and 78 rpm records.

RIAA position gives best performance of Stereo LP records.
